型號 |
流量(m³/h) | 揚程 |
轉速 | 效率(%) | 軸功率(KW) | 電機功率(KW) | 必需汽蝕余量 | 泵重量(Kg) | 報價 |
DG155-67*6 | 100 155 185 |
465 402 348 |
2950 | 280 0 0 |
229.48 | 280.00 | 5 | 0 | |
DG155-67*5 | 100 155 185 |
388 335 290 |
2950 | 220 0 0 |
191.23 | 220.00 | 5 | 0 | |
DG85-67*9 | 55 85 100 |
666 603 549 |
2950 | 250 0 0 |
214.60 | 250.00 | 4 | 0 | |
DG85-67*8 | 55 85 100 |
592 536 488 |
2950 | 220 0 0 |
190.80 | 220.00 | 4 | 0 | |
DG85-67*7 | 55 85 100 |
518 469 427 |
2950 | 200 0 0 |
166.90 | 200.00 | 4 | 0 | |
DG85-67*6 | 55 85 100 |
444 402 366 |
2950 | 160 0 0 |
143.10 | 160.00 | 4 | 0 | |
DG85-67*5 | 55 85 100 |
370 335 305 |
2950 | 132 0 0 |
119.30 | 132.00 | 4 | 0 | |
DG85-67*4 | 55 85 100 |
296 268 244 |
2950 | 110 0 0 |
95.40 | 110.00 | 4 | 0 | |
DG85-67*3 | 55 85 100 |
222 201 183 |
2950 | 90 0 0 |
71.50 | 90.00 | 4 | 0 | |
DG85-45*9 | 55 85 100 |
459 405 351 |
2950 | 160 0 0 |
130.20 | 160.00 | 4.2 | 0 | |
DG85-45*8 | 55 85 100 |
408 360 312 |
2950 | 132 0 0 |
115.70 | 132.00 | 4.2 | 0 | |
DG85-45*7 | 55 85 100 |
357 315 273 |
2950 | 132 0 0 |
101.30 | 132.00 | 4.2 | 0 | |
DG85-45*6 | 55 85 100 |
306 270 234 |
2950 | 110 0 0 |
86.81 | 110.00 | 4.2 | 0 | |
DG85-45*5 | 55 85 100 |
255 225 195 |
2950 | 90 0 0 |
72.34 | 90.00 | 4.2 | 0 | |
DG85-45*4 | 55 85 100 |
204 180 156 |
2950 | 75 0 0 |
57.87 | 75.00 | 4.2 | 0 | |
DG85-45*3 | 55 85 100 |
153 135 117 |
2950 | 55 0 0 |
43.40 | 55.00 | 4.2 | 0 | |
DG85-45*2 | 55 85 100 |
102 90 78 |
2950 | 37 0 0 |
28.94 | 37.00 | 4.2 | 0 | |
DG46-50*12 | 30 46 55 |
666 600 552 |
2950 | 132 0 0 |
119.30 | 132.00 | 2.8 | 0 | |
DG46-50*11 | 30 46 55 |
610 550 506 |
2950 | 132 0 0 |
109.40 | 132.00 | 2.8 | 0 | |
DG46-50*10 | 30 46 55 |
550 500 460 |
2950 | 132 0 0 |
99.42 | 132.00 | 2.8 | 0 | |
DG46-50*9 | 30 46 55 |
500 450 414 |
2950 | 110 0 0 |
89.50 | 110.00 | 2.8 | 0 | |
DG46-50*8 | 30 46 55 |
440 400 368 |
2950 | 90 0 0 |
79.54 | 90.00 | 2.8 | 0 | |
DG46-50*7 | 30 46 55 |
388 350 322 |
2950 | 90 0 0 |
69.60 | 90.00 | 2.8 | 0 | |
DG46-50*6 | 30 46 55 |
333 300 276 |
2950 | 75 0 0 |
59.65 | 75.00 | 2.8 | 0 | |
DG46-50*5 | 30 46 55 |
277 250 230 |
2950 | 55 0 0 |
49.71 | 55.00 | 2.8 | 0 | |
DG46-50*4 | 30 46 55 |
222 200 184 |
2950 | 45 0 0 |
39.77 | 45.00 | 2.8 | 0 | |
DG46-50*3 | 30 46 55 |
166 150 138 |
2950 | 37 0 0 |
29.83 | 37.00 | 2.8 | 0 | |
DG46-30*10 | 30 46 55 |
340 300 270 |
2950 | 75 0 0 |
53.70 | 75.00 | 3 | 0 | |
DG46-30*9 | 30 46 55 |
306 270 243 |
2950 | 55 0 0 |
48.32 | 55.00 | 3 | 0 | |
DG46-30*8 | 30 46 55 |
274 240 216 |
2950 | 55 0 0 |
42.95 | 55.00 | 3 | 0 | |
DG46-30*7 | 30 46 55 |
238 210 189 |
2950 | 45 0 0 |
37.60 | 45.00 | 3 | 0 | |
DG46-30*6 | 30 46 55 |
204 180 162 |
2950 | 37 0 0 |
32.21 | 37.00 | 3 | 0 | |
DG46-30*5 | 30 46 55 |
170 150 135 |
2950 | 37 0 0 |
26.85 | 37.00 | 3 | 0 | |
DG46-30*4 | 30 46 55 |
136 120 108 |
2950 | 30 0 0 |
21.48 | 30.00 | 3 | 0 | |
DG46-30*3 | 30 46 55 |
102 90 81 |
2950 | 22 0 0 |
16.11 | 22.00 | 3 | 0 | |
DG25-50*12 | 15 25 30 |
624 600 588 |
2950 | 110 0 0 |
75.60 | 110.00 | 2.6 | 0 | |
DG25-50*11 | 15 25 30 |
572 550 539 |
2950 | 90 0 0 |
69.30 | 90.00 | 2.6 | 0 | |
DG25-50*10 | 15 25 30 |
520 500 490 |
2950 | 75 0 0 |
63.00 | 75.00 | 2.6 | 0 | |
DG25-50*9 | 15 25 30 |
468 450 441 |
2950 | 75 0 0 |
56.70 | 75.00 | 2.6 | 0 | |
DG25-50*8 | 15 25 30 |
416 400 392 |
2950 | 75 0 0 |
50.40 | 75.00 | 2.6 | 0 | |
DG25-50*7 | 15 25 30 |
364 350 343 |
2950 | 55 0 0 |
44.10 | 55.00 | 2.6 | 0 | |
DG25-50*6 | 15 25 30 |
312 300 294 |
2950 | 45 0 0 |
37.80 | 45.00 | 2.6 | 0 | |
DG25-50*5 | 15 25 30 |
260 250 245 |
2950 | 37 0 0 |
31.50 | 37.00 | 2.6 | 0 | |
DG25-50*4 | 15 25 30 |
208 200 196 |
2950 | 30 0 0 |
25.20 | 30.00 | 2.6 | 0 | |
DG25-50*3 | 15 25 30 |
156 150 147 |
2950 | 30 0 0 |
18.90 | 30.00 | 2.6 | 0 | |
DG25-30*10 | 15 25 30 |
340 300 275 |
2950 | 45 0 0 |
32.90 | 45.00 | 2.2 | 0 | |
DG25-30*9 | 15 25 30 |
306 270 247.5 |
2950 | 37 0 0 |
29.65 | 37.00 | 2.2 | 0 | |
DG25-30*8 | 15 25 30 |
272 240 220 |
2950 | 37 0 0 |
26.40 | 37.00 | 2.2 | 0 | |
DG25-30*7 | 15 25 30 |
238 210 192.5 |
2950 | 30 0 0 |
23.10 | 30.00 | 2.2 | 0 | |
DG25-30*6 | 15 25 30 |
204 180 165 |
2950 | 30 0 0 |
19.77 | 30.00 | 2.2 | 0 | |
DG25-30*5 | 15 25 30 |
170 150 137.5 |
2950 | 22 0 0 |
16.47 | 22.00 | 2.2 | 0 | |
DG25-30*4 | 15 25 30 |
136 120 110 |
2950 | 18.5 0 0 |
13.10 | 18.50 | 2.2 | 0 | |
DG25-30*3 | 15 25 30 |
102 90 82.5 |
2950 | 15 0 0 |
9.88 | 15.00 | 2.2 | 0 | |
DG12-25*12 | 7.5 12.5 15 |
338 300 275 |
2950 | 30 0 0 |
18.90 | 30.00 | 2 | 0 | |
DG12-25*11 | 7.5 12.5 15 |
310 275 253 |
2950 | 22 0 0 |
17.34 | 22.00 | 2 | 0 | |
DG12-25*10 | 7.5 12.5 15 |
282 250 230 |
2950 | 22 0 0 |
15.76 | 22.00 | 2 | 0 | |
DG12-25*9 | 7.5 12.5 15 |
254 225 207 |
2950 | 18.5 0 0 |
14.18 | 18.50 | 2 | 0 | |
DG12-25*8 | 7.5 12.5 15 |
225.6 200 184 |
2950 | 18.5 0 0 |
12.61 | 18.50 | 2 | 0 | |
DG12-25*7 | 7.5 12.5 15 |
197 175 161 |
2950 | 15 0 0 |
11.00 | 15.00 | 2 | 0 | |
DG12-25*6 | 7.5 12.5 15 |
169 150 138 |
2950 | 15 0 0 |
9.46 | 15.00 | 2 | 0 | |
DG12-25*5 | 7.5 12.5 15 |
141 125 115 |
2950 | 11 0 0 |
7.88 | 11.00 | 2 | 0 | |
DG12-25*4 | 7.5 12.5 15 |
113 100 92 |
2950 | 11 0 0 |
6.30 | 11.00 | 2 | 0 | |
DG12-25*3 | 7.5 12.5 15 |
84.6 75 69 |
2950 | 7.5 0 0 |
4.73 | 7.50 | 2 | 0 | |
DG6-25*12 | 3.75 6.3 7.5 |
306 300 294 |
2950 | 18.5 0 0 |
12.26 | 18.50 | 2 | 0 | |
DG6-25*11 | 3.75 6.3 7.5 |
281 275 269 |
2950 | 18.5 0 0 |
11.23 | 18.50 | 2 | 0 | |
DG6-25*10 | 3.75 6.3 7.5 |
255 250 245 |
2950 | 18.5 0 0 |
10.21 | 18.50 | 2 | 0 | |
DG6-25*9 | 3.75 6.3 7.5 |
229.5 225 220 |
2950 | 15 0 0 |
9.19 | 15.00 | 2 | 0 | |
DG6-25*8 | 3.75 6.3 7.5 |
204 200 196 |
2950 | 15 0 0 |
8.17 | 15.00 | 2 | 0 | |
DG6-25*7 | 3.75 6.3 7.5 |
178.5 175 171.5 |
2950 | 11 0 0 |
7.15 | 11.00 | 2 | 0 | |
DG6-25*6 | 3.75 6.3 7.5 |
153 150 147 |
2950 | 11 0 0 |
6.13 | 11.00 | 2 | 0 | |
DG6-25*5 | 3.75 6.3 7.5 |
127.5 125 122.5 |
2950 | 7.5 0 0 |
5.11 | 7.50 | 2 | 0 | |
DG6-25*4 | 3.75 6.3 7.5 |
102 100 98 |
2950 | 7.5 0 0 |
4.09 | 7.50 | 2 | 0 | |
DG6-25*3 | 3.75 6.3 7.5 |
76.5 75 73.5 |
2950 | 5.5 0 0 |
3.06 | 5.50 | 2 | 0 |
